핵심 특징

상세 사양

• Mixing Capacity - Input Channels
  48 mono
• Mixing Capacity - Mix Buses
  24
• Mixing Capacity - Matrices
  12
• Mixing Capacity - Stereo Buses
  2
• Mixing Capacity - Mono Buses
  1 (Stereo B can be changed)
• Mixing Capacity - Cue Buses
  1
• General - Analog Input
  16
• General - Analog Output
  16
• General - Dante
  Primary / Secondary
• General - Expansion Slot (PY Slot)
  1
• General - MIDI
  No (MIDI protocol supported)
• General - USB TO DEVICE
  2 (USB Type-C, File Save/Load, 2Tr Rec/Play)
• General - USB TO HOST
  1 (USB Type-C, USB2.0)
• General - Ethernet
  Yes
• General - Meter Bridge
  On screen
• General - Phones
  1
• General - AC
  1 (V-Lock Type)
• Audio - Sampling Frequency (Internal)
  48 kHz / 96 kHz
• Audio - Sampling Frequency (External)
  48 kHz / 96 kHz ±200 ppm
• Audio - Signal Delay
  1.5 ms 미만 (INPUT to OMNI OUT, Fs=96 kHz)
• Audio - Frequency Response
  +0.5 / -1.5 dB, 20 Hz-20 kHz (GAIN +64 dB)
• Audio - Total Harmonic Distortion
  0.15% (+4 dBu, 20 Hz-20 kHz, GAIN +64 dB)
• Audio - Hum & Noise (EIN)
  -128 dBu (Rs=150 Ω, GAIN +64 dB)
• Audio - Hum & Noise
  -83 dBu (Rs=150 Ω, GAIN 0 dB)
• Audio - Residual Output Noise
  -88 dBu (출력 채널 OFF)
• Audio - Dynamic Range (AD+DA)
  109 dB (GAIN 0 dB)
• Audio - Dynamic Range (DA)
  114 dB (DA Converter)
• Audio - Crosstalk
  -100 dB (인접 입력 / 입력-출력 간)
• Scene Memory - Number of Scenes
  500
• Scene Memory - Recall Safe
  Yes
• Scene Memory - Focus Recall
  Yes
• Scene Memory - Fade Time
  Yes
• Scene Memory - Selective Load/Save
  Yes
• Scene Memory - Global Paste
  Yes
• Input Ch - Input A/B
  Yes
• Input Ch - Gain Compensation
  Yes
• Input Ch - Digital Gain
  Yes (-96 dB to +24 dB)
• Input Ch - Attenuator
  Yes (-96 dB to +24 dB)
• Input Ch - HPF
  20 Hz-2,000 Hz, -6/-12/-18/-24 dB/oct
• Input Ch - PEQ
  4 Band Full PEQ (4 algorithms, RTA overlay)
• Input Ch - Dynamics 1/2 (1-4)
  Legacy Comp/Comp260/Gate/De-Esser
• Input Ch - Dynamics 1/2 (5-8)
  Expander/Ducking/FET Limiter/Diode Bridge Comp
• Input Ch - Input Delay
  Yes (0 ms to 1,000 ms)
• Input Ch - Pan
  Center Nominal / LR Nominal
• Input Ch - DCA Group
  12 (Output DCA supported)
• Input Ch - DCA Rollout
  Yes
• Input Ch - MUTE Group
  12
• Input Ch - Number of Inserts
  4 slots on 1 insert point
• Input Ch - Dan Dugan Automixer
  Yes (12ch, 라이선스로 최대 64ch 확장)
• Input Ch - Direct Out
  Yes
• Output Ch - PEQ
  8 Band Full PEQ
• Output Ch - GEQ
  Virtual Rack (EQ Rack)
• Output Ch - Dynamics 1
  Input Ch와 동일 (8종)
• Output Ch - Output Channel Delay
  Yes (0 ms to 1,000 ms)
• Output Ch - MUTE Group
  12
• Output Ch - Number of Inserts
  4 slots on 1 insert point
• Premium Rack - DSP Resources
  0 (PY-DSP 장착 시 최대 32)
• Premium Rack - Mountable Plug-ins
  RND Portico5033/5043, Portico 5045, U76 등
• Effect Rack - DSP Resources
  16
• Effect Rack - Effect Types
  43
• EQ Rack - DSP Resources
  24
• EQ Rack - Mountable Devices
  31BandGEQ / Flex15GEQ / 8Band PEQ
• Dante - I/O Channels
  64 in / 64 out
• Dante - Discoverable Devices
  127
• Dante - Mountable Devices
  24
• Dante - HA Remote Control Devices
  24
• Dante - Patch from Console
  Yes
• USB to Host - Audio I/O Channels
  18 in / 18 out
• USB to Host - USB MIDI
  Yes
• Monitor - Solo Mode
  Yes
• Monitor - Oscillator
  Sine Wave 1ch/2ch, Pink Noise, Burst Noise
• Other - Port to Port
  Yes
• Other - GPI
  Yes (with PY-MIDI-GPI)
• Other - MIDI
  Yes (USB MIDI)
• Other - OSC Server
  Yes
• Other - DAW Remote
  Yes
• Other - Nuendo Live Control Integration
  Yes
• Other - Virtual Soundcheck
  Yes
• Other - Wireless Mic Monitoring
  Yes
• Other - RTA
  Yes
• Other - Delay Compensation
  Yes
• Other - Output Port Delay
  Yes (Up to 20 ports)
• Other - Sub In
  Yes
• Other - User Levels
  Yes
• Other - Channel Link
  Yes
• Other - Temporary Channel Link
  Yes
• Other - Multi Language Channel Names
  Yes
• Other - Mix/Matrix to Input
  Yes
• Other - Assist
  Yes (HA / Naming / Comp / Fader)
• UI - Displays
  13.3인치 멀티터치 x1, 4.3인치 멀티터치 x1
• UI - Faders
  13 (12+1), 100 mm 모터라이즈드
• UI - Channel Name/Color Displays
  No (on-screen)
• UI - Custom Fader Banks
  Yes
• UI - Shift Keys
  Yes (on-screen)
• UI - User Defined Keys
  Glass Keys 6, Screen 6 (6키 x4뱅크)
• UI - User Defined Knobs
  Yes (스크린 옆 4개 엔코더)
• UI - Touch and Turn Knobs
  Yes
• UI - Rack Mountable
  Yes (RK5 랙 마운트 키트)
• Software - Editor
  DM Editor (Win/Mac)
• Software - StageMix
  DM StageMix
• Software - MonitorMix
  Yes
• Software - Console File Converter
  Yes
• Software - ProVisionaire Control PLUS/Kiosk
  Yes
• Software - Package
  Broadcast / Theatre / Dugan Automixer 라이선스
• Dimensions - Width
  446 mm (17.6인치)
• Dimensions - Height
  235 mm (9.3인치, 고무발 포함)
• Dimensions - Depth
  441 mm (17.4인치)
• Dimensions - Net Weight
  13.3 kg (29.3 lb)
• Power - Power Requirements
  100 to 240 V, 50/60 Hz
• Power - Power Consumption
  130 W
• Power - Operating Temperature
  0℃ to 40℃
• Power - Storage Temperature
  -20℃ to 60℃
• Power - NC Value
  NC=20 (Fan LOW) / NC=25 (Fan HIGH)
• Included Accessories
  Read This First, 전원 코드, 더스트 커버, 케이블 훅
• Optional Accessories
  PY 카드, RK5 랙 마운트 키트
